GN-ZB-350XSF wholesale pillow packaging machine for the hardware industry is a kind of automatic induction length identification packaging machine independently developed by guonuo company, which is specially designed for all kinds of aluminum materials, guide rails, hardware accessories, hoses, bathroom shower pipes, PVC pipes, and other products with different lengths.
| Machine Model | GN-ZB-350XSF |
| Film Width | Max 340mm |
| Bag Length | Suitable different lengths according to the product |
| Bag Width | 50-150mm |
| Product Height | Max 55mm |
| Film Roll Diameter | Max 320mm |
| Packing Speed | 10-25m/min |
| Power Supply | 220Vac 56/60Hz 2.4KW |
| Machine Dimension | L4000 × W760 × H1370mm |
| Gross Weight | 550Kg |
| Remarks: The packaging film can be connected under the normal working state of the machine, saving time and high efficiency | |
Flow wrappers are popular because they're simple and make an attractive package for products that covers many industries, like Guonuo's GN-ZB-350XSF horizontal ffs machine .
They can also be wicked fast, with some producing 300 packages per minute (ppm) or more. A more common speed is 50 ppm to 200 ppm.
| Main Parts Configuration (In case of replacement, the same grade shall prevail) | ||
| No. | Components | Brand |
| 1 | PLC | PANASONIC JAPAN |
| 2 | Inverter | PANASONIC JAPAN / SHIHLIN TAIWAN |
| 3 | Touch Screen | XINJIE/MCGS CHINA |
| 4 | Temperature Controller | ALSET CHINA |
| 5 | Photocell | ALSET CHINA |
| 6 | Encoder | RONGDE CHINA |
| 7 | Two Position Switch | GLELE CHINA |
| 8 | Proximity Switch | ENVK TAIWAN |
| 9 | Power | MINGWEI TAIWAN |
| 10 | Solid State Relay | SCHNEIDER GERMANY |
| 11 | Intermediate Relay | OMRON JAPAN |
